Portfolio

Machine Development Projects

Selected projects from our work with CNC machine builders and industrial equipment manufacturers.

CNC Router

3-axis gantry-style CNC router designed for large-format sheet material processing. Welded steel frame optimized for structural stiffness and vibration damping.

View Case Study →

Variable-Speed Mini Lathe

Compact variable-speed metal lathe with precision spindle assembly and hardened bed ways. Designed for educational and light-duty workshop applications.

View Case Study →

Automatic Cut & Weld Station

Integrated cutting and robotic welding cell with automated material handling. Designed for high-volume production of structural steel components.

View Case Study →

Industrial Drum Sieve

Heavy-duty rotary drum screen for bulk material separation. Designed for continuous operation in demanding industrial environments.

View Case Study →

Industrial Lime Mixer

Lime mixing system integrated into an existing bulk material processing plant. Designed with rings, connection joints, pipes, clamps, and nozzles for continuous operation.

View Case Study →

Industrial Cooling Unit

Bulk material cooling unit with optimized flow channels, barriers, and pipe routing. Migrated from SolidWorks to Autodesk Inventor with further design improvements.

View Case Study →

Rotary Valve H-AR Series

Complete product line of rotary airlock valves spanning eight size variants with flanged connections for bulk material handling.

View Case Study →

Industrial Pipe Scrapers

Heavy-duty pipeline scrapers for DN 800 and DN 1500 pipe diameters. Designed for cleaning and maintenance of large-diameter industrial pipelines.

View Case Study →

Conveying Air Dosing Station

Pneumatic conveying air unit dosing station series for controlled bulk material transport. Steel frame structure with hoppers and air injection system.

View Case Study →

CNC Spindles & 2-Axis Heads

High-precision machine tooling components including motors, spindles, 2-axis heads, 2-axis rotary tables, and testing benches embedded in CNC machines.

View Case Study →

2-Axis Table Test Bench

High-precision 3-axis gantry test bench for automated measurement of 2-axis rotary tables with servo-driven axes and micron-level accuracy targets.

View Case Study →
